So I have the Celestron OAG and the ASI174MM-Mini guide camera. The stars barely show up, even at 2 second exposures. Will the guiding be sufficient enough if I bump it up to 3 or even 5 seconds? I would think that the shorter exposure times would be much better for faster corrections. Do I need a better guide camera that is more sensitive? Here's what HighPointScientific has to say about the 174:
"Looking for a highly sensitive monochrome guide camera or planetary camera? Then look no further than this ASI174MM Mini!"
Not sure how this camera is "sensitive". I am using the Celestron 0.7 reducer on the 8" EdgeHD, bringing the f-stop to f7. Not sure what else I can change other than the exposure time, but I am worried that the longer exposures would make the whole OAG useless, since I can use a 200mm guide scope (not recommended on this scope) at 0.5 seconds with no issues.
|
You cannot like this item. Reason: "ANONYMOUS".
You cannot remove your like from this item.
Editing a post is only allowed within 24 hours after creating it.
You cannot Like this post because the topic is closed.
Copy the URL below to share a direct link to this post.
This post cannot be edited using the classic forums editor.
To edit this post, please enable the "New forums experience" in your settings.
Hi.
I have the Celestron OAG and ASI174MM-Mini with my EdgeHD 9.25 and I have no problems getting stars. Is the prism maybe too far back? And/or have you tried without the reducer?
|
You cannot like this item. Reason: "ANONYMOUS".
You cannot remove your like from this item.
Editing a post is only allowed within 24 hours after creating it.
You cannot Like this post because the topic is closed.
Copy the URL below to share a direct link to this post.
This post cannot be edited using the classic forums editor.
To edit this post, please enable the "New forums experience" in your settings.
In PHD2 you can turn up the gain. The gain value shown in PHD2 is a percentage of the maximum gain on the camera. Try setting this to 60 or 70 and see if that makes a difference.
|
You cannot like this item. Reason: "ANONYMOUS".
You cannot remove your like from this item.
Editing a post is only allowed within 24 hours after creating it.
You cannot Like this post because the topic is closed.
Copy the URL below to share a direct link to this post.
This post cannot be edited using the classic forums editor.
To edit this post, please enable the "New forums experience" in your settings.
Lasse Skov:
Hi.
I have the Celestron OAG and ASI174MM-Mini with my EdgeHD 9.25 and I have no problems getting stars. Is the prism maybe too far back? And/or have you tried without the reducer? I think removing the reducer would make it worse at f10. I am also not sure if adjusting the prism would really make a difference, worth looking into though. Thanks.
|
You cannot like this item. Reason: "ANONYMOUS".
You cannot remove your like from this item.
Editing a post is only allowed within 24 hours after creating it.
You cannot Like this post because the topic is closed.
Copy the URL below to share a direct link to this post.
This post cannot be edited using the classic forums editor.
To edit this post, please enable the "New forums experience" in your settings.
Dark Matters Astrophotography:
In PHD2 you can turn up the gain. The gain value shown in PHD2 is a percentage of the maximum gain on the camera. Try setting this to 60 or 70 and see if that makes a difference. I am using the ASIAIR, which uses PHD2, but I didn't see (or look for) a setting in PHD2 for gain. The camera is at max gain, but I'll look for a setting, thanks. EDIT: There is no "gain" setting in PHD2 on the ASIAIR. The camera is at max gain though, max allowable. I did read this in another forum though: "Go to 4, 5 even 6 secs, unless you have a rickety mount." I guess I can try 5 seconds, I was just worried this would reduce the effectiveness of the auto-guiding.
|
You cannot like this item. Reason: "ANONYMOUS".
You cannot remove your like from this item.
Editing a post is only allowed within 24 hours after creating it.
You cannot Like this post because the topic is closed.
Copy the URL below to share a direct link to this post.
This post cannot be edited using the classic forums editor.
To edit this post, please enable the "New forums experience" in your settings.
The reducer actually reduces the imaging circle, so even though it gets "faster" it delivers less light in the outer parts of the FOV. So I would still try without the reducer attached, it's not all about F-stop. Moving the prism is actually crucial to whether or not it will gather light, and bring it to the guide sensor.
I have to remove my reducer (permanently) for other reasons though I was able to successfully use my OAG with it, BUT not unless the prism protruded into the imaging cam's FOV. I'm guessing that a C8HD, APS-C and the 0.7x reducer might be pushing it beyond what it's capable of.
|
You cannot like this item. Reason: "ANONYMOUS".
You cannot remove your like from this item.
Editing a post is only allowed within 24 hours after creating it.
You cannot Like this post because the topic is closed.
Copy the URL below to share a direct link to this post.
This post cannot be edited using the classic forums editor.
To edit this post, please enable the "New forums experience" in your settings.
The reducer actually reduces the imaging circle, so even though it gets "faster" it delivers less light in the outer parts of the FOV. So I would still try without the reducer attached, it's not all about F-stop. Moving the prism is actually crucial to whether or not it will gather light, and bring it to the guide sensor.
I have to remove my reducer (permanently) for other reasons though I was able to successfully use my OAG with it, BUT not unless the prism protruded into the imaging cam's FOV. I'm guessing that a C8HD, APS-C and the 0.7x reducer might be pushing it beyond what it's capable of. Right, but on many forums, the Celestron OAG and ASI174MM are a perfect match. I don't have any vignetting, or blurry stars, it's just a faintness issue. I am going to try 5 seconds, since I haven't gone over 2 seconds, but mainly because I am worried that a higher exposure time would reduce the effectiveness of the guiding.
|
You cannot like this item. Reason: "ANONYMOUS".
You cannot remove your like from this item.
Editing a post is only allowed within 24 hours after creating it.
You cannot Like this post because the topic is closed.
Copy the URL below to share a direct link to this post.
This post cannot be edited using the classic forums editor.
To edit this post, please enable the "New forums experience" in your settings.
RM Haley:
Right, but on many forums, the Celestron OAG and ASI174MM are a perfect match. I don't have any vignetting, or blurry stars, it's just a faintness issue. I am going to try 5 seconds, since I haven't gone over 2 seconds, but mainly because I am worried that a higher exposure time would reduce the effectiveness of the guiding. Yes it is, but clearly you have an issue that needs sorting which is most likely related to what has been responded to you in this thread. You should not need those exposure lengths to see stars, especially with gain at max. If you are using HD mounts you would ideally need less than 1s exposures for guiding, EQ mounts could do with more than that. If you have a camera with a small sensor then you would not see any vignetting at all. Those turn up with APS-C. Vignetting on your imaging cam also has nothing to do with whatever the guide camera sees or not. 1. The reducer reduces the imaging circle, less light and more warped stars towards the corners. Setting the OAG prism too far up will result in: low light, faint stars, oblong stars and or issues with getting proper guiding for all the above reasons. 2. Removing the reducer will give the opposite effect, despite being F/10 which doesn't really matter as much because aperture is more important, much more important than F-ratio. So I would re-check the position of your OAG prism. Make sure that you see it clearly getting light through the reducer but still not obscuring your imaging sensor. It should be very easy to do with small sensors up to 4/3.
|
You cannot like this item. Reason: "ANONYMOUS".
You cannot remove your like from this item.
Editing a post is only allowed within 24 hours after creating it.
You cannot Like this post because the topic is closed.
Copy the URL below to share a direct link to this post.
This post cannot be edited using the classic forums editor.
To edit this post, please enable the "New forums experience" in your settings.
I use an OAG with the 174 on my Edge-11, with the 0.7 reducer installed. My main camera is a full-frame ASI2400mc-p. In order to keep the prism out of the camera's FOV, it is really into the vignetted drop-off area. If I'm imaging near the galactic plane, finding guide stars is not an issue usually (max gain and using 1 sec exposures), but if I'm in a low-density star field area shooting, for instance, an isolated galaxy, I sometimes have to rotate the OAG (changing the target framing) to find a good guide star. And sometimes, I do need to bump up the exposure time to make that work.
Curious if you (OP) have used the 200mm guide scope you mentioned with any success on your rig?
|
You cannot like this item. Reason: "ANONYMOUS".
You cannot remove your like from this item.
Editing a post is only allowed within 24 hours after creating it.
You cannot Like this post because the topic is closed.
Copy the URL below to share a direct link to this post.
This post cannot be edited using the classic forums editor.
To edit this post, please enable the "New forums experience" in your settings.
Richard Carande:
I use an OAG with the 174 on my Edge-11, with the 0.7 reducer installed. My main camera is a full-frame ASI2400mc-p. In order to keep the prism out of the camera's FOV, it is really into the vignetted drop-off area. If I'm imaging near the galactic plane, finding guide stars is not an issue usually (max gain and using 1 sec exposures), but if I'm in a low-density star field area shooting, for instance, an isolated galaxy, I sometimes have to rotate the OAG (changing the target framing) to find a good guide star. And sometimes, I do need to bump up the exposure time to make that work.
Curious if you (OP) have used the 200mm guide scope you mentioned with any success on your rig? Yeah, I was originally using a 200mm guide scope with the ASI120MM-S, and that worked great. What I have found though using the OAG is that the images are a bit more crisp. I originally did it for the stars, initially, but I have seen a dramatic improvement in the targets as well. I have looked into some forums, and it seems like I can bump it up from 2 second exposures to up to 5 second exposures without any real issue, as long as you have a good mount, and I am using the EQ6-R Pro.  |
You cannot like this item. Reason: "ANONYMOUS".
You cannot remove your like from this item.
Editing a post is only allowed within 24 hours after creating it.
You cannot Like this post because the topic is closed.
Copy the URL below to share a direct link to this post.
This post cannot be edited using the classic forums editor.
To edit this post, please enable the "New forums experience" in your settings.
Yes it is, but clearly you have an issue that needs sorting which is most likely related to what has been responded to you in this thread. You should not need those exposure lengths to see stars, especially with gain at max. If you are using HD mounts you would ideally need less than 1s exposures for guiding, EQ mounts could do with more than that.
If you have a camera with a small sensor then you would not see any vignetting at all. Those turn up with APS-C. Vignetting on your imaging cam also has nothing to do with whatever the guide camera sees or not.
1. The reducer reduces the imaging circle, less light and more warped stars towards the corners. Setting the OAG prism too far up will result in: low light, faint stars, oblong stars and or issues with getting proper guiding for all the above reasons.
2. Removing the reducer will give the opposite effect, despite being F/10 which doesn't really matter as much because aperture is more important, much more important than F-ratio.
So I would re-check the position of your OAG prism. Make sure that you see it clearly getting light through the reducer but still not obscuring your imaging sensor. It should be very easy to do with small sensors up to 4/3.
I am using the ASI533 and ASI294 on this EdgeHD 8", and I can't use the ASI2600 with the reducer. The prism on the Celestron OAG is massive, and I don't think I can move it any closer to the sensor as it barely fits as it is with the 294. I think without the reducer things might be fine, and I could probably do 1 second guiding exposures, but with the reducer I might be stuck just increasing the exposure up to 5 seconds. Is what it is I guess, and as long as it works, I don't care.
|
You cannot like this item. Reason: "ANONYMOUS".
You cannot remove your like from this item.
Editing a post is only allowed within 24 hours after creating it.
You cannot Like this post because the topic is closed.
Copy the URL below to share a direct link to this post.
This post cannot be edited using the classic forums editor.
To edit this post, please enable the "New forums experience" in your settings.
RM Haley:
Dark Matters Astrophotography:
In PHD2 you can turn up the gain. The gain value shown in PHD2 is a percentage of the maximum gain on the camera. Try setting this to 60 or 70 and see if that makes a difference.
I am using the ASIAIR, which uses PHD2, but I didn't see (or look for) a setting in PHD2 for gain. The camera is at max gain, but I'll look for a setting, thanks.
EDIT: There is no "gain" setting in PHD2 on the ASIAIR. The camera is at max gain though, max allowable. I did read this in another forum though:
"Go to 4, 5 even 6 secs, unless you have a rickety mount."
I guess I can try 5 seconds, I was just worried this would reduce the effectiveness of the auto-guiding. Before you do that check the position of the prism and also make sure that enough light is getting in for the prism to be effective. If you can use adapters with the largest possible opening this should allow more light in for the prism which will in turn allow for more signal from the guide stars.
|
You cannot like this item. Reason: "ANONYMOUS".
You cannot remove your like from this item.
Editing a post is only allowed within 24 hours after creating it.
You cannot Like this post because the topic is closed.
Copy the URL below to share a direct link to this post.
This post cannot be edited using the classic forums editor.
To edit this post, please enable the "New forums experience" in your settings.
So I don't know what happened, I didn't really make any changes but all of a sudden the stars were fine at 1 second with max gain.
|
